PARAMETER

  • Model No.QDSH-PJS8136

  • Load Capacity3600kg

MACHINE SIZE

Model No. QDSH-PJS8136
Lifting capacity 3600KG
Max height 1880mm
Minimum height 120mm
Overall height 2158mm
Overall length 4295mm
Lifting time 50S
Motor voltage 380V/220V
Motor Power 2.2KW
Package size 4300*570*770mm

FEATURES

◆The post and platform made with steel p late bend.

◆Square pipe deem design

◆Cylinder front fixed pattern eliminating cylinder fracture.

◆Platform pitch adjustable for various vehicles

◆P neumatic synchronous unlocking design

◆Every cylinder passes the pressure test

◆Accord with standard of European Union CE
